The database schema is defined in prisma/schema.prisma and managed via Prisma ORM targeting a MariaDB (MySQL-compatible) backend. The datasource provider is set to mysql and reads the connection string from the DATABASE_URL environment variable. To apply the schema in a development environment run npx prisma db push; for production deployments with tracked migrations use npx prisma migrate deploy.
Use npx prisma db push during development for rapid iteration — it applies schema changes directly without creating migration files. In production, always use npx prisma migrate deploy with versioned migration files to avoid untracked schema drift and potential data loss.
Run npx prisma studio during development to open a visual browser-based GUI for inspecting and editing rows in every table. This is significantly faster than writing raw SQL queries when debugging ticket or warn data.
GuildSettings
Table: guild_settings
Stores the per-guild configuration populated by /setup and kept up-to-date via /config. Every guild that runs /setup gets exactly one row keyed on its Discord guild ID.
model GuildSettings {
guildId String @id @map("guildId")
logsChannel String?
debugChannel String?
verifyChannel String?
welcomeChannel String?
supportChannel String?
roleUser String?
roleNoVerify String?
roleMuted String?
staffRoles String? // JSON array of staff role IDs
ticketLogsChannel String?
ticketPanelChannel String?
ticketPanelMessage String?
isSetup Boolean @default(false)
@@map("guild_settings")
}
| Field | Type | Description |
|---|
guildId | String (PK) | Discord guild/server ID. Primary key — one row per server. |
logsChannel | String? | Channel ID where audit log embeds (member joins, edits, bans, role changes) are sent. |
debugChannel | String? | Channel ID where bot errors and debug output are posted. Redirectable via /set-debug. |
verifyChannel | String? | Channel ID where the verification button panel (posted by /set-verify) lives. |
welcomeChannel | String? | Channel ID for Canvas welcome card images sent on guildMemberAdd. |
supportChannel | String? | Channel ID for the informational support/rules message posted by /set-support. Also used as the isolation zone for spam offenders. |
roleUser | String? | Role ID granted to a member after successful verification. |
roleNoVerify | String? | Role ID assigned to unverified members when they first join. |
roleMuted | String? | Role ID for muted/isolated users (spam offenders, manual mutes). |
staffRoles | String? | JSON-serialised array of role IDs considered staff (e.g. ["123", "456"]). Used by /stats and the dashboard for staff analytics. |
ticketLogsChannel | String? | Channel ID where ticket transcripts and close-event embeds are archived. Set via /ticket setlogs. |
ticketPanelChannel | String? | Channel ID where the active ticket creation panel was posted. Stored so the panel can be refreshed or replaced. |
ticketPanelMessage | String? | Message ID of the ticket panel embed, enabling in-place edits when categories change. |
isSetup | Boolean | false by default. Set to true when /setup completes successfully. The /config dashboard displays a red warning when this is false. |
Warn
Table: warns
Tracks the current warning count for each user per guild. Uses a composite primary key so counts are independent across different servers. The roles field is a JSON string snapshot of the user’s role IDs at the moment they were isolated, enabling /unmute to fully restore their original role set.
model Warn {
guildId String
userId String
count Int @default(0)
roles String? // JSON String
@@id([guildId, userId])
@@index([guildId])
@@map("warns")
}
| Field | Type | Description |
|---|
guildId | String (PK part 1) | Discord guild ID — part of the composite primary key. |
userId | String (PK part 2) | Discord user ID — part of the composite primary key. |
count | Int | Current accumulated warning count. Resets to 0 after the 3-warn timeout is applied or after /reset-warns is run. |
roles | String? | JSON-serialised array of the user’s role IDs saved before isolation (e.g. ["111","222"]). Read by /unmute to restore roles. |
WarnLog
Table: warn_logs
Immutable audit trail for every individual warning action. Unlike the warns table (which stores the current state), warn_logs is append-only and provides the full history surfaced by /history.
model WarnLog {
id Int @id @default(autoincrement())
userId String
moderatorId String
reason String? @db.Text
warnNumber Int
timestamp DateTime @default(now())
@@index([userId])
@@index([timestamp])
@@map("warn_logs")
}
| Field | Type | Description |
|---|
id | Int (PK) | Auto-incrementing primary key. |
userId | String | The Discord user ID of the warned member. Indexed for fast lookup by /history. |
moderatorId | String | The Discord user ID of the moderator who issued the warning. |
reason | String? | Free-text reason for the warning. Stored as TEXT to support long explanations. Max 1000 characters enforced at the command level. |
warnNumber | Int | The warn count at the moment this log entry was created (e.g. 1, 2, or 3). |
timestamp | DateTime | UTC timestamp when the warning was issued. Indexed for time-range queries. |
Ticket
Table: tickets
Represents a single active or closed support ticket. Heavily indexed to support the /ticket metrics dashboard queries and the inactivity reminder background job.
model Ticket {
ticketId Int @id @default(autoincrement())
guildId String
userId String
channelId String?
status String @default("open")
type String?
claimedBy String?
transcriptUrl String?
lastActivity DateTime @default(now())
createdAt DateTime @default(now()) @map("created_at")
@@index([guildId])
@@index([status])
@@index([guildId, status])
@@index([guildId, status, claimedBy])
@@index([userId])
@@index([channelId])
@@map("tickets")
}
| Field | Type | Description |
|---|
ticketId | Int (PK) | Auto-incrementing primary key. |
guildId | String | The Discord guild ID the ticket belongs to. |
userId | String | The Discord user ID of the member who opened the ticket. |
channelId | String? | The Discord channel ID of the private ticket channel. Used by the inactivity reminder to ping the channel. |
status | String | Ticket lifecycle status: "open", "closed", or "archived". Default is "open". |
type | String? | The ticket category name selected by the user from the panel SelectMenu. |
claimedBy | String? | Discord user ID of the staff member who claimed the ticket via claim_ticket. Null if unclaimed. |
transcriptUrl | String? | URL path to the generated HTML transcript file stored locally on the server. |
lastActivity | DateTime | Updated whenever a new message is posted in the ticket channel. Drives the inactivity reminder logic. |
createdAt | DateTime | UTC timestamp when the ticket was created. |
TicketCategory
Table: ticket_categories
Configuration record for each ticket category created via /ticket add. The panel SelectMenu is dynamically generated from all rows in this table for the given guild.
model TicketCategory {
id Int @id @default(autoincrement())
guildId String
name String
description String?
emoji String?
roleId String?
targetCategoryId String?
createdAt DateTime @default(now()) @map("created_at")
@@map("ticket_categories")
}
| Field | Type | Description |
|---|
id | Int (PK) | Auto-incrementing primary key. |
guildId | String | Discord guild ID the category belongs to. |
name | String | Display name of the category, shown in the SelectMenu and ticket channel names. |
description | String? | Brief description shown as the SelectMenu option description. |
emoji | String? | Emoji prefix displayed next to the category name in the panel (e.g. 🔧). |
roleId | String? | JSON-serialised string of one or more role IDs that have access to tickets in this category. Supports multiple roles added via /ticket addrole. |
targetCategoryId | String? | Discord Category channel ID where ticket channels are created. |
createdAt | DateTime | UTC timestamp when the category was created. |
TicketAction
Table: ticket_actions
Append-only audit log for ticket lifecycle events. Every claim, transfer, and close action produces a row here, enabling the /ticket metrics command to build staff productivity rankings.
model TicketAction {
id Int @id @default(autoincrement())
ticketId Int
action String
executorId String
targetId String?
timestamp DateTime @default(now())
@@index([ticketId])
@@index([timestamp])
@@map("ticket_actions")
}
| Field | Type | Description |
|---|
id | Int (PK) | Auto-incrementing primary key. |
ticketId | Int | References the ticketId in the tickets table. Indexed for per-ticket history lookups. |
action | String | The action taken: "claim", "transfer", or "close". |
executorId | String | Discord user ID of the staff member who performed the action. |
targetId | String? | Discord user ID of the transfer recipient (populated only for "transfer" actions). |
timestamp | DateTime | UTC timestamp of the action. Indexed for metrics time-range queries. |
WhitelistLog
Table: whitelist_logs
Records every approve (aprobado) and reject (rechazado) action performed by the Whitelist Bot. A unique constraint on [userId, action] prevents a user from having more than one record per action type — attempting to approve an already-approved user will upsert the existing row rather than create a duplicate.
model WhitelistLog {
id Int @id @default(autoincrement())
userId String
userTag String?
moderatorId String
moderatorTag String?
action String @default("aprobado") // "aprobado", "rechazado"
note String?
timestamp DateTime @default(now())
@@unique([userId, action])
@@map("whitelist_logs")
}
| Field | Type | Description |
|---|
id | Int (PK) | Auto-incrementing primary key. |
userId | String | Discord user ID of the applicant. |
userTag | String? | Discord username tag of the applicant at the time of the decision (snapshot). |
moderatorId | String | Discord user ID of the staff member who made the decision. |
moderatorTag | String? | Discord username tag of the moderator at the time of the decision (snapshot). |
action | String | Either "aprobado" (approved) or "rechazado" (rejected). Defaults to "aprobado". |
note | String? | Optional note attached by the moderator at the time of the /aprobar or /rechazar command. |
timestamp | DateTime | UTC timestamp of the whitelist decision. |
ActivityLog
Table: activity_logs
General-purpose activity log written to by utils/logger.js and consumed by /stats, the web dashboard, and background cleanup jobs. Logs are automatically pruned after the configured retention period (default: 30 days).
model ActivityLog {
id Int @id @default(autoincrement())
guildId String
userId String?
action String? @db.Text
timestamp DateTime @default(now())
@@index([guildId])
@@index([userId])
@@index([guildId, timestamp])
@@map("activity_logs")
}
| Field | Type | Description |
|---|
id | Int (PK) | Auto-incrementing primary key. |
guildId | String | Discord guild ID the event belongs to. Indexed for per-guild dashboard queries. |
userId | String? | Discord user ID associated with the action, if applicable. |
action | String? | Human-readable description of the event, stored as TEXT for long audit entries (e.g. message content snapshots). |
timestamp | DateTime | UTC timestamp of the event. The composite index on [guildId, timestamp] supports efficient time-range dashboard queries. |
User
Table: users
Persisted Discord user profiles used by the web dashboard to display usernames and avatars without making a live Discord API call on every page load. Populated and refreshed by the background profile update job in web/utils/userFetcher.js.
model User {
id String @id
username String
avatar String?
tag String?
discriminator String?
lastSeenAt DateTime @default(now()) @map("last_seen_at")
updatedAt DateTime @updatedAt @map("updated_at")
@@index([updatedAt])
@@map("users")
}
| Field | Type | Description |
|---|
id | String (PK) | Discord user snowflake ID. |
username | String | Current Discord username. |
avatar | String? | Discord avatar hash used to construct the CDN avatar URL. |
tag | String? | Cached username tag (e.g. Username#0000 for legacy accounts). |
discriminator | String? | Four-digit discriminator for legacy Discord accounts. "0" for accounts migrated to the new username system. |
lastSeenAt | DateTime | Timestamp of the last bot interaction by this user. Mapped to last_seen_at in SQL. |
updatedAt | DateTime | Auto-managed Prisma @updatedAt timestamp. Indexed for the batch refresh job to find stale profiles. |
SystemError
Table: system_errors
Records unhandled bot errors for post-mortem debugging. Application code (commands, event handlers) writes to this table via logError() in utils/logger.js. The global unhandledRejection and uncaughtException handlers in both entry points write to structured log files via utils/structuredLogger.js rather than directly to this table. Rows can be reviewed via /db-tables or Prisma Studio.
model SystemError {
id Int @id @default(autoincrement())
context String?
message String? @db.Text
stack String? @db.Text
timestamp DateTime @default(now())
@@map("system_errors")
}
| Field | Type | Description |
|---|
id | Int (PK) | Auto-incrementing primary key. |
context | String? | Short label describing where in the codebase the error occurred (e.g. "Finalizar Setup Wizard"). |
message | String? | The JavaScript Error.message string, stored as TEXT. |
stack | String? | The full Error.stack trace, stored as TEXT for deep debugging. |
timestamp | DateTime | UTC timestamp when the error was recorded. |
