The DSVPN client establishes an encrypted TCP connection to the server, then sets up a TUN interface and routing rules so that all traffic from the device is tunnelled through the server. Like the server, the client applies and removes all network configuration automatically — no manual routing or firewall commands required.

​
Connecting

sudo ./dsvpn client vpn.key 34.216.127.34 1959
Replace 34.216.127.34 with the public IP address or hostname of your DSVPN server, and 1959 with the port it is listening on. The port argument is optional when the server uses the default port 443:
sudo ./dsvpn client vpn.key my-server.example.com
Once connected, DSVPN prints Connected and all traffic from the device is routed through the VPN. Press Ctrl-C to disconnect.

​
What Happens on Connect

After the TCP connection and cryptographic handshake succeed, DSVPN performs all routing setup automatically. The exact commands depend on the operating system.
DSVPN sets up a policy routing scheme on Linux that avoids routing loops. The VPN’s own TCP socket is excluded from the policy table using a socket mark (SO_MARK=42069), so tunnelled traffic never recursively re-enters the VPN.BBR congestion control — enabled system-wide for better performance on the outer TCP socket:
sysctl net.ipv4.tcp_congestion_control=bbr
TUN interface setup
ip link set dev <tun> up
iptables -t raw -I PREROUTING ! -i <tun> -d 192.168.192.1 -m addrtype ! --src-type LOCAL -j DROP
ip addr add 192.168.192.1 peer 192.168.192.254 dev <tun>
ip -6 addr add 64:ff9b::192.168.192.1 peer 64:ff9b::192.168.192.254/96 dev <tun>
Policy routing table 42069 — all unmarked traffic uses a separate routing table that sends everything through the TUN:
ip route add default dev <tun> table 42069
ip -6 route add default dev <tun> table 42069
ip rule add not fwmark 42069 table 42069
ip -6 rule add not fwmark 42069 table 42069
ip rule add table main suppress_prefixlength 0
ip -6 rule add table main suppress_prefixlength 0
The VPN’s own TCP socket to the server is marked with SO_MARK=42069, so it looks up the main routing table and reaches the server directly — preventing a routing loop.

​
Automatic Reconnection

The DSVPN client reconnects automatically if the connection drops — for example, when a laptop wakes from sleep, switches between Wi-Fi networks, or loses connectivity briefly.
  • The client retries up to 100 times (RECONNECT_ATTEMPTS).
  • Backoff delay between attempts: 0 s, 1 s, 2 s, 3 s, then 3 s for all subsequent attempts.
  • If the default network gateway IP changes between reconnect attempts (e.g., the device joined a different network), DSVPN detects the change, tears down the old routing rules, updates the gateway, and re-applies the rules before reattempting the connection.
  • If all 100 attempts fail, DSVPN exits with an error. Restart it manually or via a process supervisor.
The server never attempts to reconnect — it simply waits for the next incoming TCP connection.

​
IPv6 Leak Prevention

IPv6 leaks are a common VPN pitfall: when a device has a working IPv6 address, OS resolvers or applications may send traffic via IPv6, bypassing the VPN tunnel entirely. DSVPN addresses this automatically:
  • macOS/BSD: adds blackhole routes for 0000::/1 and 8000::/1, which together cover the entire IPv6 address space. Any IPv6 traffic is silently discarded rather than sent outside the tunnel.
  • Linux: routes IPv6 through the TUN interface using the NAT64-prefix tunnel addresses (64:ff9b::<ipv4>).
No manual configuration is needed. IPv6 connectivity is blocked for the duration of the VPN session and restored when DSVPN exits.

​
Disconnecting

Press Ctrl-C or send SIGTERM to the DSVPN process:
sudo kill -TERM <dsvpn-pid>
DSVPN removes all routing rules and TUN interface configuration it applied, restoring the network to its original state. The disconnect is clean regardless of whether the server is still reachable.

​
iOS Client

An iOS client for DSVPN is available as a separate project:

dsvpn-ios

Native iOS client for DSVPN. Uses the same shared-key authentication and connects to any standard DSVPN server.
DNS may continue using the pre-VPN resolver after connecting. If your VPN server is meant to provide DNS privacy, configure your system DNS to use a public or local resolver (such as 1.1.1.1, 8.8.8.8, or a local DNSCrypt proxy) in addition to running DSVPN. DSVPN does not redirect DNS queries automatically.
The client detects its default gateway automatically using the system routing table. If auto-detection fails (rare on unusual network setups), specify the gateway IP explicitly as the last argument:
sudo ./dsvpn client vpn.key my-server.example.com 443 auto auto auto 192.168.1.1
The gateway IP is the address of your local router — the first hop shown by netstat -rn (look for the Gateway column on the default 0.0.0.0 route).
